3ton Backhoe Loader Machine Backhoe Wheel Loader With Weifang 6102 Engine
| Place of Origin | China |
|---|---|
| Brand Name | Hengwang |
| Certification | CE |
| Model Number | HW-30 |
| Minimum Order Quantity | 1 |
| Price | USD2500-5000/set |
| Packaging Details | Wooden box, container, etc |
| Delivery Time | 5-8 workdays |
| Payment Terms | D/P , T/T ，Western Union |
| Supply Ability | Negotiable |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model | HW-30 | Rated Load (Ton) | 3 |
|---|---|---|---|
| Engine Model | Weifang 6102 Supercharger | Max. Discharging Height (mm) | 5300 |
| Bucket Width (mm) | 2400 | Rated Bucket Capacity (m³) | 1.7 |
| High Light | 3ton Backhoe Loader Machine,3ton Backhoe Wheel Loader,Weifang Engine Backhoe Loader Machine |
||
Product Description
Loader is a kind of earthwork construction machinery widely used in highway, railway, construction, hydropower, port, mine and other construction projects. It is mainly used for shoveling bulk materials such as soil, sand, lime, coal, etc. , hard soil, etc. for light shoveling operations. By replacing different auxiliary working devices, it can also carry out bulldozing, lifting and loading and unloading of other materials such as wood.
In road construction, especially high-grade highway construction, loaders are used for filling and excavation of roadbed projects, aggregate and loading of asphalt mixtures and cement concrete yards. In addition, it can also carry out operations such as pushing soil, scraping the ground and pulling other machinery. Because the loader has the advantages of fast operating speed, high efficiency, good maneuverability, and light operation, it has become one of the main types of machines for earth and stone construction in engineering construction.
The main parameters:
| Model | HW-30 |
| vehicle size(mm) | 7200*2350*3300 |
| unloading height(m) | 3.8 |
| lift height(m) | 5.3 |
| vehicle weight(kg) | 9600 |
| engine model | Weichai6102 |
| form | turbocharged |
| engine power(kw) | 92KW |
| torque converter | 320 |
| bridge | National standard 30 bridge |
| tire | 17.5-25 |
| Bucket width(mm) | 2400 |
| Rated bucket capacity(m³) | 1.7 |
| Rated load capacity(kg) | 3000 |
| Minimum ground clearance(mm) | 420 |
| wheelbase(mm) | 1930 |
| Wheelbase(mm) | 3150 |
